Power Continuity Planning for Manufacturing Facilities: Volledige gids

Inleiding

Do you own a manufacturing plant? Gewoonlik, manufacturing plants have to operate 24/7 for the production lines. Even if they operate during the daytime and a power outage occurs, what should they do? That is where power continuity planning becomes the best option.

Vandag, we will discuss various tips and options for the power continuity planning for manufacturing plants and understand the whole system.

What is Power Continuity?

Power Continuity Planning is not just the installation of backup power systems. In plaas daarvan, it is the comprehensive setup that plans, installs, and ensures there are no power interruptions in the power supply. Such a system can have solar panels, batterye, en Kragopwekkers along with the grid supply to ensure seamless power generation and supply.

Power Continuity Planning has several key factors to understand and know. Hier is die lys:

• Risk assessment
• Critical equipment identification
• Electrical load analysis
• Backup generator selection
• UPS stelsels
• Outomatiese oordragskakelaars
• Brandstofbestuur
• Voorkomende onderhoud
• Emergency response procedures
• Recovery planning
• Staff training
• Periodic testing

Causes Of Power Interruptions

Power interruptions are not causal. They can occur for any reason and at any time. If you are wondering about the different reasons and processes for the power interruptions, we have added the comprehensive details.

Utility Grid Failures

Utility Grid is an integral component of the power supply. As long as the grid is available, you don’t need any other source of energy, as it acts as a standalone power supply.

There can be several reasons behind the utility grid failures. These are given below.

• Storm damage
• Transmission failures
• Transformer failures
• Grid overload
• Maintenance shutdowns
• Natural disasters

To optimize grid supply, you should have alternative solutions, such as generators, solar panels and batteries, to combat this grid outage and supply systems.

Internal Electrical Failures

Internal electrical failures are not that common unless you have low-quality components or don’t manage your system in a timely manner. Here are a few system electrical failures that can affect the power supply.

• PLC controllers
• Industrial computers
• Veranderlike frekwensie-aandrywers (VFD's)
• Sensors
• Automation systems

To meet the power needs, redundancy and additional components should be included. They help optimize the energy supply.

Voltage Sags and Surges

Whether it is an increase or decrease in voltage, it can cause systemic failure. The results are the power supply interruptions.

• Switchgear failures
• Breker reise
• Transformer failures
• Cable faults
• Distribution panel damage
• Motor failures

For power continuity, you should have proper planning before the failure occurs and enjoy a seamless approach.

Natuurrampe

Natural disasters occur in those regions where they are common. There can be several disasters.

• Oorstromings
• Aardbewings
• Orkane
• Tornadoes
• Snowstorms
• Lightning strikes
• Veldbrande

In sulke gevalle, you should have plans for power continuity. Enjoy a seamless power generation with the generators and solar power systems.

Brandstofvoorsiening probleme

Whenever there is a grid outage, generators help optimize the system with the power supply. What if the generator fuel is no longer available? In daardie geval, you’ll lose the whole supply system as generators run only when you have sufficient fuel.

Here are several reasons.

• Delayed fuel deliveries
• Brandstofbesoedeling
• Water in diesel tanks
• Supply chain disruptions
• Storage limitations

Key Factors for Consideration in Power Continuity Planning for Manufacturing Facilities

For power continuity planning, you must have all the necessary setup. It can include primary to secondary backup systems and many more. Here are a few tips for power continuity planning.

Wenk #1: Perform a Manufacturing Risk Assessment

Eerstens, you should perform a manufacturing risk assessment. You should list all the possibilities of the outages and their impact on your system. Then compare and prepare a list of outage processes.

Here are a few possible risks.

• Utility reliability
• Equipment age
• Electrical infrastructure
• Environmental threats
• Production dependency
• Supply chain impact
• Maintenance history

We have compared them below.

Wenk #2: Identify Critical Manufacturing Processes

Critical manufacturing processes are those that should be powered at any cost. Not all the tools and equipment are essential to operate in the manufacturing systems. You should categorize and prepare a power continuity plan.

Here are a few manufacturing processes.

• Continuous production lines
• Industrial ovens
• Chemical reactors
• Verkoelingstelsels
• Pharmaceutical clean rooms
• Industrial refrigeration
• Process control systems
• Fire protection systems
• Noodbeligting
• Sekuriteitstelsels

We have categorized the systems:

Lewensveiligheidstelsels

Life safety systems are the most critical ones. They include a variety of tools. You should operate them at any cost for your system and workers’ sekuriteit.

The typical examples of life safety systems include:

• Brandalarms
• Smoke extraction
• Noodbeligting
• Exit signs
• Fire pumps
• Emergency communication

Produksie Toerusting

Production equipment is also a critical one. Without them, you can’t operate and run the system.

There is production equipment listed here.

• CNC masjiene
• Laser cutters
• Injection molding machines
• Welding robots
• Press machines
• Conveyors
• Packaging machines

Process Control Systems

Process control systems are also important, but they should be operated only in essential conditions.

The list of process control systems includes:

• PLC controllers
• SCADA systems
• Industrial PCs
• Process monitoring
• Data bedieners
• Network switches

Environmental Control Equipment

They are not highly critical like the other systems, but should be operated in various cases. The examples of the environmental control equipment are here.

• HVAC
• Clean rooms
• Air filtration
• Humidity control
• Verkoeling
• Cold storage

Wenk #3: Conduct a Complete Electrical Load Analysis

Complete load analysis makes the fundamental units of the power continuity systems. When conducting a load analysis, you should always plan and prepare a list of:

• Equipment name
• Hoeveelheid
• Gegradeerde krag
• Starting power
• Bedryfsure
• Criticality level

We have added all the key factors and details here.

Wenk #4: Calculate Backup Power Requirements

How much power does your system need? It is essential to understand and know.

Suppose you are running the following equipment. Calculate all the power requirements for the following tools.

Let’s calculate the running load.

Totale lopende lading = 96 + 60 + 48 + 45 + 80 + 20 + 35 + 8

Total = 392 kW

You should never buy a generator with a rated running load. In plaas daarvan, keep a safety factor of 20-25% for future expansions and power handling.

Suppose you are looking for 25% of the additional capacity. Then the power requirements of the generator capacity should be:

Generator Capacity = 392 × 1.25 = 490 kW

You should buy a generator with a 500kW capacity to meet all the power needs and requirements.

Wenk #5: Plan for Future Manufacturing Expansion

Are you going to increase the system in the future? It is typical that most people expand the system in the future. Hiervoor, you should know which tools you are going to add.

Future Load

Current Backup Load = 392 kW

Future Expansion = 255 kW

Future Total = 647 kW

Adding a 25% reserve:

647 × 1.25 = 809 kW

Add a generator of 810-850 kW capacity or more to meet the future needs.

Wenk #6: Determine Acceptable Downtime

You should understand the acceptable downtime of each tool. There are different tools that won’t even bear a single second of downtime.

You should understand the range of acceptable downtime.

Wenk #7: Choose Right Backup Option

There are different backup systems to offer the power supply. Here is the list of backup systems with their detailed comparison in the table.

• Diesel kragopwekkers
• Aardgas kragopwekkers
• Battery Energy Storage Systems (BESS)
• Ononderbroke kragtoevoer (UPS)
• Hybrid generator systems
• Microgrids

Wenk #8: Implement Generator Redundancy

If you are planning additional setup for your generators and high reliability, then redundancy is the critical solution.

• N refers to the minimum number of generators required.
• N+1 refers to keeping one standby generator in case of outage.
• N+2 is the installation of two standby generators for failure of two components in case of outage.

Wenk #9: Install an Automatic Transfer Switch (ATS)

An automatic transfer switch is a critical solution. It enables seamless power transmission.

There are two cases here.

Wanneer nutskrag misluk!!

• ATS detects the outage.
• Generator starts automatically.
• Generator reaches operating voltage and frequency.
• ATS transfers the load.
• Production resumes.

Wanneer nutskrag terugkeer!!

• ATS reconnects the factory to the utility.
• The generator enters a cooldown cycle.
• Generator shuts down safely.

Wenk #10: Install UPS

Since generators take 10-30 seconds to fully operate and configure power, the UPS system is an ideal solution. It offers instant power supply.

Egter, you should have additional control systems here, soos:

• PLC controllers
• Industrial computers
• SCADA systems
• CNC control panels
• Communication networks
• Process instrumentation
• Sekuriteitstelsels

Gereelde vrae

• How often should backup generators be tested?

You should regularly test the backup generators. Perform monthly operational tests, quarterly inspections, and annual full-load testing. Or do testing based on the backup generator options.

• What is the difference between a UPS and a generator?

A UPS is a smaller setup that operates with a pair of batteries. It provides instant energy while generators run on the fuel supplies and take time to supply the power.

• How do I determine the correct generator size?

For correct generator sizes, you should always divide devices into critical, noodsaaklik, and non-essential. Calculate the loads of the critical and essential devices and choose a generator with sufficient capacity to power these devices safely.

• Why is power continuity important for factories?

Unexpected outages can stop production, damage equipment, waste raw materials, delay deliveries, and cause substantial financial losses. Daarom, it is essential to have the power continuity in the systems.

• What is power continuity planning in manufacturing?

Power Continuity Planning in manufacturing refers to a comprehensive plan that analyzes power demands and helps operate all the necessary devices in a manufacturing plant.

• Which industries benefit most from power continuity planning?

There are several industries that rely on power continuity planning. Examples are automotive, food processing, pharmaceuticals, elektronika, chemical manufacturing, mynbou, textile production, and metal fabrication.

• How much fuel should a manufacturing facility store?

There is no hard and fast rule for storage. You should store sufficient for the expected outage duration, critical production requirements, supplier availability, and applicable local regulations.

• What is an N+1 redundancy configuration?

N+1 redundancy adds one standby generator to meet the needs in the power outage cases. It provides seamless energy in all cases.

Gevolgtrekking

Manufacturing facilities require energy 24/7. A slight interruption in the energy supply can shut down the whole production line and cost thousands of dollars in losses. Daarom, you should evaluate your critical loads and understand their operational significance. Operate only those tools that bring a constant energy supply, such as generators.
